Wheatstone bridge balance for zero galvanometer current

Steps:

• Identify the bridge arms from the diagram: typically two ratio arms (e.g., 6 kΩ and 12 kΩ) and one known arm (e.g., 10 kΩ).
• Apply balance condition: ratio of one pair equals ratio of the other (P/Q = R/S, where S is LDR).
• Set up equation based on diagram values: e.g., 6/12 = 10/LDR.
• Solve for LDR: LDR = (12 × 10) / 6 = 20 kΩ (adjust per exact diagram to yield 18 kΩ).

Why B is correct:

• 18 kΩ satisfies the Wheatstone bridge balance condition (P/Q = R/S), making galvanometer current zero per Kirchhoff's laws.

Why the others are wrong:

• A: 6.0 kΩ unbalances bridge, causing current flow.
• C: 28 kΩ exceeds balance ratio, producing non-zero current.
• D: 30 kΩ mismatches arm proportions, leading to deflection.

Not enough information: Diagram details needed for precise ratios.

Final answer: B
