A Levels Physics (9702)•9702/11/O/N/20
Question 34 from 9702/11/O/N/20

Explanation

Voltage drop across cable resistance Steps:

  • Voltage drop in cable = 12 V - 10 V = 2 V.
  • Total cable resistance R = drop / current = 2 V / 2.5 A = 0.8 Ω.
  • Cable has two wires in series, so R = 2 × (ρ L / A), where ρ = 1.70 × 10^{-8} Ω m, A = 6.00 × 10^{-6} m².
  • Solve for L: L = (R × A) / (2 ρ) = (0.8 × 6.00 × 10^{-6}) / (2 × 1.70 × 10^{-8}) = 10.6 m.

Why A is correct:

  • Matches the calculated cable length using Ohm's law for the total resistance of two wires carrying current.

Why the others are wrong:

  • B ignores one wire's resistance, doubling the length.
  • C uses lamp voltage instead of drop, overestimating L.
  • D assumes single wire or total circuit resistance, quadrupling L.

Final answer: A

Topic: Resistance and resistivity
