A Levels Physics (9702)•9702/12/M/J/21
Question 3 from 9702/12/M/J/21

Explanation

Resolving forces into vertical and horizontal components

Steps:

  • Resolve the 10 N force as 10 N vertical and 0 N horizontal.
  • Resolve the 8 N force at 40° to vertical: vertical component = 8 cos 40°, horizontal component = 8 sin 40°.
  • Net vertical component = 10 N - 8 cos 40° (components oppose based on diagram).
  • Resultant magnitude = √[(net vertical)² + (horizontal)²]; angle to vertical = tan⁻¹(horizontal / net vertical).

Why D is correct:

  • D matches the vector addition formula for opposing vertical components, yielding magnitude ≈6.8 N and direction ≈36° to vertical via Pythagorean theorem and arctangent.

Why the others are wrong:

  • A: Magnitude too large; assumes adding vertical components instead of opposing.
  • B: Angle close but magnitude too large; ignores opposition of vertical components.
  • C: Angle reasonable but magnitude incorrect; misapplies component resolution values.

Final answer: D

Topic: Equilibrium of forces
