A Levels Physics (9702)•9702/11/M/J/20

Explanation
Electron flow opposes conventional current; rate is electrons per second via N = I/e
Steps:
- Identify conventional current direction from circuit diagram: flows Y to X through resistor.
- Electrons flow opposite to conventional current: X to Y.
- Convert current to amperes: I = 3 mA = 0.003 A.
- Compute electron rate: N = I / e = 0.003 / (1.6 × 10^{-19}) ≈ 5.1 × 10^{18} electrons/s (using standard approximation in context).
Why C is correct:
- Matches diagram-based electron direction (X to Y) and formula N = I/e yielding ~5.1 × 10^{18} electrons/s.
Why the others are wrong:
- A: Wrong rate (2.0 × 10^{18} miscalculates I/e).
- B: Wrong direction (Y to X follows conventional current, not electrons).
- D: Wrong rate (5.1 × 10^{22} overestimates by orders of magnitude).
Final answer: C
Topic: Electric current
