O Levels Physics (5054)•5054/12/O/N/18

Explanation
Torricelli's barometer setup Steps:
- Fill a long, closed tube completely with mercury and seal it.
- Invert the tube into an open dish of mercury, allowing some mercury to flow out.
- Mercury column stabilizes at a height determined by atmospheric pressure balancing the vacuum above.
- Measure the height (typically 760 mm) to find atmospheric pressure in mmHg.
Why C is correct:
- C states the space above the mercury is a Torricellian vacuum, as no air enters and mercury falls due to atmospheric pressure, per Boyle's law and vacuum definition.
Why the others are wrong:
- A: Incorrect, as the tube is initially full, not open to air.
- B: Wrong, mercury doesn't fill the entire tube; it drops to 76 cm height.
- D: False, the height varies with atmospheric pressure, not fixed at full length.
Final answer: C
Topic: Pressure
