O Levels Physics (5054)•5054/12/M/J/22
Question 36 from 5054/12/M/J/22

Explanation

Circuit path analysis with switches

Steps:

  • S1 closed allows current from battery to parallel branches containing L1-S2 and L2-L3.
  • S2 open blocks the branch with L1, preventing current flow through L1.
  • Current flows only through the L2-L3 branch in series.
  • L2 and L3 receive voltage and light up; L1 remains off.

Why C is correct:

  • Parallel branches follow Kirchhoff's current law: open switch isolates one path, directing all current to the active branch.

Why the others are wrong:

  • A: Ignores L2-L3 path, which remains open to current.
  • B: Includes L1, but S2 open blocks its branch.
  • D: Includes L1, but its path is interrupted by open S2.

Final answer: C

Topic: Series and parallel circuits
